Double-Shaft Shredding Solutions
The ideal solution for a wide range of materials and applications.
Double-shaft shredders are available in a wide range of models and configurations, with motor power ranging from 15 HP (2LD series) to 200 HP (2SHD series).
These shredders deliver high performance, reliability, and versatility across industries. Multiple rotor configurations are available at the time of equipment selection to achieve the best performance.The double-shaft shredders can include standard and custom BloApCo control panels.
All equipment includes a 1-year warranty.
Ideal For:
- Municipal Waste
- Industrial Waste
- Plastics
- Wood
- Paper
- Metals
- Rubber
Versatile
Engineered for a wide range of materials and demanding application
Durable
Heavy-duty construction built for continuous, reliable operation
Configurable
Multiple rotor and drive configurations to match your needs
Advanced Control
Standard and custom BloApCo control panels for optimal operation
Peace of Mind
Added confidence with one year of warranty protection
Why Choose the Titan Series?
Designed for demanding recycling environments, BloApCo systems offer expanded material capabilities for plastics, wood, metal, WEEE, and more. With multiple sizes and throughput capacities available, our equipment can be tailored to your specific application—all backed by BloApCo’s trusted engineering, service, and support.
Technical Specifications
| Machine Model | 2LD Starting at |
2MD Starting at |
2HD Starting at |
2SHD Starting at |
|---|---|---|---|---|
| Estimated Capacity (T/Hr)* | 0.3 – 1.5 | 1.5 – 3 | 3 – 12 | 12 – 25 |
| L x W x H – Length x Width x Height (in) | 62 x 50 x 73 | 99 x 65 x 84 | 141 x 73 x 100 | 229 x 95 x 132 |
| C – Chamber (in) | 15.7 | 31.5 | 39.4 | 70.9 |
| D – Chamber (in) | 18.5 | 27.2 | 33.5 | 58.7 |
| Blade Thickness (in)** | 0.79 | 0.79 | 1.57 | 1.97 |
| Shaft Diameter (in & mm) | 12 (284) | 17 (430) | 21 (514) | 32 (800) |
| Shaft Speed (RPM) | 17 | 15 | 15 | 7.5 |
| Rotor Knives (pc)*** | 20 | 40 | 25 | 36 |
| Motor Power**** HP (kW) | 0.7 (5.5) | 20 (15) | 40 (30) | 100 (75) |
| Gross Weight (lbs) | 1,450 | 3,600 | 6,500 | 20,100 |
*Dependent on materials and feeding applications.
**Standard alloys are 5SiCr or HARDDX550ED2. Special alloys and thicker blades available on request.
***Rotor styles and number of knives are based on the application and can vary.
****Higher power rates are available on request.
Overall dimensions are for illustration purposes. BloApCo will engineer and size the equipment based on the application and requirements.
